MCP1811BT-030/TT
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Tape & Reel (TR) Surface Mount Over Current Enable voltage regulator linear 0.4V 2.9mm 150mA -40C~85C TJ
PDF
/
Inventory: 5355
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Length 2.9mm
Technical
Input Voltage Absolute-Max 6V
Voltage Tolerance-Max 4%
Output Voltage1-Min 2.88V
Dropout Voltage1-Nom 0.4V
PSRR 50dB (1kHz)
Voltage Dropout (Max) 0.6V @ 150mA
Current - Quiescent (Iq) 0.5μA
Protection Features Over Current
Number of Regulators 1
Voltage - Output (Min/Fixed) 3V
Input Voltage (Min) 3.6V
Output Voltage 1 3V
Control Features Enable
Current - Output 150mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 5.5V
Number of Outputs 1
Current - Supply (Max) 110μA
JESD-30 Code R-PDSO-G3
Reach Compliance Code compliant
Terminal Pitch 0.95mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TR
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TJ
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
