MCP1790T-3302E/EBVAO
RoHS
RoHS compliant
RoHS compliantPackage TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1790 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 3.3825V 5.08mm 70mA -40C~125C
PDF
/
Buying Options
Total Price: USD $4.79
Unit Price: USD $4.787312
≥1 USD $4.787312
≥10 USD $4.51634
≥100 USD $4.260694
≥500 USD $4.019529
≥1000 USD $3.792006
Inventory: 1252
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 5.08mm
Technical
Output Voltage1-Max 3.3825V
PSRR 90dB ~ 80dB (100Hz ~ 1kHz)
Voltage Dropout (Max) 1.3V @ 70mA
Current - Quiescent (Iq) 130μA
Protection Features Over Current, Over Temperature, Short Circuit
Number of Regulators 1
Voltage - Output (Min/Fixed) 3.3V
Input Voltage (Min) 6V
Output Voltage 1 3.3V
Control Features Enable
Current - Output 70mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 30V
Current - Supply (Max) 210μA
JESD-30 Code R-PSSO-G3
Base Part Number MCP1790
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case TO-263-4, D2Pak (3 Leads + Tab), TO-263AA
Mounting Type Surface Mount
