MCP1755S-3302E/MC
RoHS
RoHS compliant
RoHS compliantPackage 8-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1755 Tube Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 300mV 0.5mm 300mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.6776
≥1 USD $0.6776
≥10 USD $0.582912
Inventory: 212
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VFDFN Exposed Pad
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2012
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Other Regulators
Technology CMOS
Terminal Position DUAL
Terminal Form NO LEAD
Terminal Pitch 0.5mm
Base Part Number MCP1755
JESD-30 Code R-PDSO-N8
Current - Supply (Max) 400μA
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 16V
Output Voltage 3.3V
Output Type Fixed
Output Configuration Positive
Current - Output 300mA
Quiescent Current 68μA
Output Voltage 1 3.3V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 100μA
Voltage Dropout (Max) 0.5V @ 300mA
PSRR 80dB (1kHz)
Dropout Voltage 300mV
Dropout Voltage1-Nom 0.3V
Power Supply Rejection Ratio (PSRR) 70dB
Voltage Tolerance-Max 2%
Compliance
RoHS Status ROHS3 Compliant
