MCP1702T-5002E/MBVAO
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1702 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 13.2V 2.445mm 5muA -40C~125C
PDF
/
Buying Options
Total Price: USD $4.27
Unit Price: USD $4.265076
≥1 USD $4.265076
≥10 USD $4.02366
≥100 USD $3.795905
≥500 USD $3.581043
≥1000 USD $3.378344
Inventory: 1187
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 2.445mm
Length 4.495mm
Technical
Output Voltage1-Min 4.85V
PSRR 44dB (100Hz)
Voltage Dropout (Max) 0.65V @ 250mA
Current - Quiescent (Iq) 5μA
Protection Features Over Current, Over Temperature, Short Circuit
Number of Regulators 1
Voltage - Output (Min/Fixed) 5V
Input Voltage (Min) 5.8V
Output Voltage 1 5V
Current - Output 250mA
Output Configuration Positive
Output Type Fixed
Voltage - Input (Max) 13.2V
JESD-30 Code R-PSSO-F3
Base Part Number MCP1702
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Terminal Position SINGLE
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case TO-243AA
Mounting Type Surface Mount
