MCP1700T-3302E/MBVAO
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
MCP1700 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 3.399V 4.5mm 250mA -40C~125C
PDF
/
Buying Options
Total Price: USD $0.48
Unit Price: USD $0.477029
≥1 USD $0.477029
≥10 USD $0.450026
≥100 USD $0.424548
≥500 USD $0.400519
≥1000 USD $0.377847
Inventory: 1529
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case TO-243AA
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Packing Method TR
Technology CMOS
Terminal Position SINGLE
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MCP1700
JESD-30 Code R-PSSO-F3
Number of Outputs 1
Voltage - Input (Max) 6V
Output Type Fixed
Output Configuration Positive
Current - Output 250mA
Output Voltage 1 3.3V
Input Voltage (Min) 4.3V
Voltage - Output (Min/Fixed) 3.3V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Short Circuit
Current - Quiescent (Iq) 4μA
Voltage Dropout (Max) 0.35V @ 250mA
PSRR 44dB (100Hz)
Dropout Voltage1-Nom 0.178V
Output Voltage1-Max 3.399V
Voltage Tolerance-Max 3%
Input Voltage Absolute-Max 6.5V
Dimensions
Length 4.5mm
Width 2.5mm
Compliance
RoHS Status ROHS3 Compliant
