MCP1700-3002EMB
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
FLAT Not Qualified CMOS 8542.39.00.01 voltage regulator linear 125C 0.25A 1.5mm 3.09V
PDF
/
Inventory: 7088
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 2.445mm
Length 4.5mm
Height Seated (Max) 1.6mm
Technical
Operating Temperature TJ-Min -40°C
Line Regulation-Max (%/V) 0.06%
Load Regulation-Max(%) 0.045%
Adjustability FIXED
Input Voltage Absolute-Max 6.5V
Operating Temperature TJ-Max 125°C
Dropout Voltage1-Max 0.35V
Output Current1-Max 0.25A
Voltage Tolerance-Max 3%
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Output Voltage1-Min 2.91V
Output Voltage1-Max 3.09V
Dropout Voltage1-Nom 0.178V
Input Voltage (Max) 6V
Input Voltage (Min) 3.44V
Output Voltage 1 3V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSSO-F3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form FLAT
Terminal Position SINGLE
Technology CMOS
Subcategory Other Regulators
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Physical
Surface Mount YES
