LR645N5-G
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LR645 Tube Through Hole ROHS3Compliant voltage regulator linear 15V 9.02mm 3mA 1.8kW
PDF
/
Buying Options
Total Price: USD $1.46
Unit Price: USD $1.4608
≥1 USD $1.4608
≥10 USD $1.2056
≥100 USD $1.1088
Inventory: 310
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 2.299997g
Technical
Operating Temperature -55°C~155°C
Packaging Tube
Published 2008
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Subcategory Other Regulators
Max Power Dissipation 1.8W
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number LR645
Number of Outputs 1
Voltage - Input (Max) 450V
Output Voltage 10V
Output Type Fixed
Max Output Current 3mA
Output Configuration Positive
Power Dissipation 1.8kW
Quiescent Current 150μA
Output Voltage 1 10V
Voltage - Output (Min/Fixed) 8V
Min Input Voltage 15V
PSRR 60dB (120Hz)
Power Supply Rejection Ratio (PSRR) 60dB
Voltage Tolerance-Max 15%
Voltage - Output (Max) 12V
Min Current Limit 30mA
Nominal Output Voltage 10V
Dimensions
Height 9.02mm
Length 10.67mm
Width 4.83mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
