MIC5205-3.3YM5
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
SOT-23 Surface Mount RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) voltage regulator linear 165mV 1.45mm 150mA 125C
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2147
≥1 USD $0.2147
≥10 USD $0.1767
≥100 USD $0.171
≥500 USD $0.1653
≥1000 USD $0.16055
≥6000 USD $0.14345
Inventory: 244007
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOT-23
Number of Pins 5
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 40
Number of Outputs 1
Qualification Status Not Qualified
Output Type Fixed
Max Output Current 150mA
Max Supply Voltage 16V
Min Supply Voltage 2.5V
Nominal Supply Current 10nA
Current - Output 150mA
Accuracy 2 %
Voltage - Output 3.3V
Output Voltage 1 3.3V
Min Input Voltage 2.5V
Max Input Voltage 16V
Dropout Voltage 165mV
Max Junction Temperature (Tj) 125°C
Dimensions
Height 1.45mm
Length 2.9mm
Width 1.6mm
Compliance
RoHS Status RoHS Compliant
Alternative Model
