MAX8559ETAAA+
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Positive BICMOS EAR99 Fixed voltage regulator linear 85C 1.951W 0.3A 3mm
PDF
/
Buying Options
Total Price: USD $2.12
Unit Price: USD $2.121959
≥1 USD $2.121959
≥10 USD $2.001854
≥100 USD $1.888536
≥500 USD $1.78164
≥1000 USD $1.680785
Inventory: 1435
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Number of Pins 8
Technical
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology BICMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Pin Count 8
Number of Outputs 2
Output Type Fixed
Polarity Positive
Power Dissipation-Max 1.951W
Quiescent Current 290μA
Accuracy 1 %
Output Voltage 1 3.3V
Min Input Voltage 2.5V
Max Input Voltage 6.5V
Output Current1-Max 0.3A
Output Voltage 2 3.3V
Voltage Reference 1.25V
Output Current2-Max 0.3A
Dimensions
Length 3mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
