LT3086HFE#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LT3086 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 0.33V 5mm 2.1A -40C~150C TJ
PDF
/
Inventory: 2157
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Packing Method TR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.65mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LT3086
Pin Count 16
Current - Supply (Max) 88mA
Number of Outputs 1
Voltage - Input (Max) 40V
Output Type Adjustable
Output Configuration Positive
Current - Output 2.1A
Control Features Current Limit, Enable, Power Good, Tracking
Voltage - Output (Min/Fixed) 0.4V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 2.4mA
Voltage Dropout (Max) 0.54V @ 2.1A
PSRR 80dB (120Hz)
Dropout Voltage1-Nom 0.33V
Output Voltage1-Min 0.4V
Voltage - Output (Max) 32V
Load Regulation-Max(%) 0.25%
Input-Output Voltage Differential-Max 39.6V
Dimensions
Length 5mm
Width 4.4mm
Compliance
RoHS Status RoHS Compliant
