LT3009EDC-2.5#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
LT3009 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity voltage regulator linear 2.55V 2mm 20mA -40C~125C
PDF
/
Inventory: 8817
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-WFDFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LT3009
Pin Count 6
JESD-30 Code S-PDSO-N6
Current - Supply (Max) 1mA
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 20V
Output Type Fixed
Output Configuration Positive
Current - Output 20mA
Control Features Enable
Output Voltage 1 2.5V
Voltage - Output (Min/Fixed) 2.5V
Number of Regulators 1
Protection Features Over Current, Over Temperature, Reverse Polarity
Current - Quiescent (Iq) 6μA
Voltage Dropout (Max) 0.45V @ 20mA
PSRR 63dB (120Hz)
Dropout Voltage1-Nom 0.28V
Output Voltage1-Max 2.55V
Output Voltage1-Min 2.45V
Voltage Tolerance-Max 2%
Input Voltage Absolute-Max 22V
Dimensions
Height Seated (Max) 0.8mm
Length 2mm
Width 2mm
Compliance
RoHS Status ROHS3 Compliant
