TLE7469GV53XT
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
GULL WING 8542.39.00.01 FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR DUAL voltage regulator linear 150C 0.7A 7.5mm 5.1V
PDF
/
Inventory: 9336
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount YES
Number of Pins 12
Technical
Number of Terminations 12
ECCN Code EAR99
HTS Code 8542.39.00.01
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Output Voltage 1 5V
Input Voltage (Min) 5.6V
Input Voltage (Max) 45V
Output Voltage1-Max 5.1V
Output Voltage1-Min 4.9V
Regulator Type FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR
Output Current1-Max 0.7A
Dropout Voltage1-Max 0.6V
Operating Temperature TJ-Max 150°C
Output Voltage 2 2.6V
Operating Temperature TJ-Min -40°C
Output Voltage2-Max 2.7V
Output Voltage2-Min 2.5V
Output Current2-Max 0.5A
Dimensions
Height Seated (Max) 2.6mm
Length 7.5mm
Width 6.4mm
Compliance
RoHS Status RoHS Compliant
