UCC3941N-5
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
CURRENT-MODE Non-RoHS Compliant Fixed Positive Switching Regulator IC 0C~70C TA 200kHz 500mW 200mA
PDF
/
Buying Options
Total Price: USD $1.91
Unit Price: USD $1.9096
≥1 USD $1.9096
Inventory: 872
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
ECCN Code EAR99
Subcategory Switching Regulator or Controllers
Technology BICMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number UCC3941
JESD-30 Code R-PDIP-T8
Function Step-Up
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 5.5V
Output Voltage 5V
Output Type Fixed
Voltage - Input (Min) 0.8V
Input Voltage-Nom 1.25V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Current - Output 200mA
Output Power 500mW
Topology Boost
Control Mode CURRENT-MODE
Synchronous Rectifier Yes
Switching Frequency-Max 200kHz
Dimensions
Height Seated (Max) 5.08mm
Length 9.59mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
