TPS62403DRCT
RoHS
RoHS compliant
RoHS compliantPackage 10-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
TPS62403 ALSO HAS PFM CONTROL TECHNIQUE; ALSO OPERATES IN ADJUSTABLE MODE FROM 0.6TO 6V Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au) DC to DC switching regulator 3.6V 3mm 400mA 600mA 2.25MHz
PDF
/
Buying Options
Total Price: USD $1.73
Unit Price: USD $1.7336
≥1 USD $1.7336
≥10 USD $1.55408
≥100 USD $1.466432
≥500 USD $1.249512
Inventory: 547
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 3mm
Length 3mm
Height 1mm
Technical
Min Output Voltage 1.1V
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 2.25MHz
Control Mode VOLTAGE-MODE
Topology Buck
Voltage - Output (Min/Fixed) 1.1V 1.575V 2.8V
Max Output Voltage 1.575V
Quiescent Current 32μA
Current - Output 400mA 600mA
Output Configuration Positive
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.5V
Operating Supply Voltage 6V
Max Output Current 400mA
Output Type Programmable (Fixed)
Output Voltage 1.575V
Efficiency 95 %
Qualification Status Not Qualified
Number of Outputs 2
Function Step-Down
Base Part Number TPS62403
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Additional Feature ALSO HAS PFM CONTROL TECHNIQUE; ALSO OPERATES IN ADJUSTABLE MODE FROM 0.6 TO 6V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 25.089328mg
Number of Pins 10
Surface Mount YES
Package / Case 10-VFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
Alternative Model
