TPS62097QWRGTRQ1
RoHS
RoHS compliant
RoHS compliantPackage 16-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
TPS62097 Tape & Reel (TR) UVLO Matte Tin (Sn) DC to DC switching regulator 6V 3mm 2A 1.5MHz~2.5MHz
PDF
/
Buying Options
Total Price: USD $1.92
Unit Price: USD $1.9184
≥1 USD $1.9184
≥10 USD $1.72392
≥100 USD $1.626592
≥500 USD $1.385824
≥1000 USD $1.301203
≥3000 USD $1.138544
Inventory: 1840
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount, Wettable Flank
Package / Case 16-VFQFN Exposed Pad
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100, iDCS-Control
JESD-609 Code e3
Feature UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number TPS62097
Function Step-Down
Number of Outputs 1
Output Voltage 6V
Output Type Adjustable
Voltage - Input (Min) 2.5V
Input Voltage-Nom 3.6V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Current - Output 2A
Voltage - Output (Min/Fixed) 0.8V
Topology Buck
Frequency - Switching 1.5MHz~2.5MHz
Input Voltage (Max) 6V
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Dimensions
Height 1mm
Length 3mm
Width 3mm
Thickness 900μm
Compliance
RoHS Status ROHS3 Compliant
