TPS6208818YFPR
RoHS
RoHS compliant
RoHS compliantPackage 6-XFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
ROHS3Compliant Fixed Positive BOTTOM DC to DC switching regulator -40C~125C TJ 4MHz 3A 0.8mm
PDF
/
Buying Options
Total Price: USD $195.65
Unit Price: USD $195.64585
≥1 USD $195.64585
≥10 USD $175.4061
Inventory: 603
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 0.8mm
Height Seated (Max) 0.5mm
Technical
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 4MHz
Topology Buck
Voltage - Output (Min/Fixed) 1.8V
Current - Output 3A
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 5V
Voltage - Input (Min) 2.4V
Output Type Fixed
Output Voltage 1.8V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Function Step-Down
JESD-30 Code R-XBGA-B6
Base Part Number TPS6208818
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Series DCS-Control?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 6-XFBGA, DSBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
