TPS62026DRCRG4
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
IC REG BUCK 3.3V 0.6A SYNC 10SON
PDF
/
Buying Options
Total Price: USD $2.01
Unit Price: USD $2.011745
≥1 USD $2.011745
≥10 USD $1.897882
≥100 USD $1.790456
≥500 USD $1.689103
≥1000 USD $1.593493
Inventory: 1311
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Technical
Switcher Configuration BUCK
Min Output Voltage 3.3V
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 6V
Frequency - Switching 1.25MHz
Control Mode VOLTAGE-MODE
Min Input Voltage 2.5V
Voltage - Output 3.3V
Max Output Voltage 3.3V
Quiescent Current 18μA
Current - Output 600mA
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Temperature Grade INDUSTRIAL
Input Voltage-Nom 3.6V
Operating Supply Voltage 6V
Max Output Current 600mA
Output Type Fixed
Output Voltage 3.3V
Efficiency 95 %
Number of Outputs 1
Pin Count 10
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Subcategory Switching Regulator or Controllers
Additional Feature ALSO HAS CONTROL TECHNIQUE OF PFM
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 2
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 25.089328mg
Number of Pins 10
Surface Mount YES
