TPS61280DYFFT
RoHS
/
Package 16-UFBGA, DSBGA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
TPS61280 ALSO OPERATES IN PFM CONTROL TECHNIQUE Tape & Reel (TR) Tin/Silver/Copper (Sn/Ag/Cu) DC to DC switching regulator 3.2V 0m 5A Switch 2.3MHz
PDF
/
Buying Options
Total Price: USD $1.45
Unit Price: USD $1.452
≥1 USD $1.452
≥10 USD $1.30504
≥100 USD $1.230944
≥500 USD $1.048784
Inventory: 454
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Thickness 425μm
Width 0m
Length 0m
Height 625μm
Technical
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 2.3MHz
Control Mode CURRENT-MODE
Topology Boost
Voltage - Output (Min/Fixed) 2.85V
Current - Output 5A Switch
Output Configuration Positive
Analog IC - Other Type BATTERY CHARGE CONTROLLER
Input Voltage-Nom 3.2V
Voltage - Input (Min) 2.3V
Output Type Programmable
Output Voltage 4.4V
Voltage - Input (Max) 4.85V
Number of Outputs 1
Function Step-Up
Base Part Number TPS61280
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Additional Feature ALSO OPERATES IN PFM CONTROL TECHNIQUE
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-UFBGA, DSBGA
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 20 Weeks
