TPS56C215RNNR
RoHS
RoHS compliant
RoHS compliantPackage 18-VFQFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
TPS56C215 Tape & Reel (TR) ACTIVE (Last Updated: 20hours ago) Active DC to DC switching regulator 12V 3.5mm 12A 400kHz 800kHz 1.2MHz
PDF
/
Buying Options
Total Price: USD $1.07
Unit Price: USD $1.07445
≥1 USD $1.07445
≥10 USD $0.8816
≥100 USD $0.85405
≥500 USD $0.8265
≥1000 USD $0.79895
Inventory: 222109
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 3.5mm
Length 3.5mm
Height 1mm
Technical
Min Output Voltage 600mV
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 400kHz 800kHz 1.2MHz
Topology Buck
Voltage - Output (Min/Fixed) 0.6V
Max Output Voltage 5.5V
Quiescent Current 600μA
Current - Output 12A
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 12V
Voltage - Input (Min) 4.5V
Output Type Adjustable
Voltage - Input (Max) 17V
Number of Outputs 1
Function Step-Down
Base Part Number TPS56C215
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Series SWIFT?, D-CAP2?, Eco-Mode?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 18
Package / Case 18-VFQFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 20 hours ago)
Factory Lead Time 8 Weeks
