TPS562200DDCT

Texas Instruments
RoHS
RoHS RoHS compliant
Package SOT-23-6 Thin, TSOT-23-6
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description TPS562200 Tape & Reel (TR) Matte Tin (Sn) ACTIVE (Last Updated: 1week ago) DC to DC switching regulator 12V 1.6mm 2A 650kHz
PDF
/
Buying Options
Total Price: USD $0.52
Unit Price: USD $0.5192
≥1 USD $0.5192
≥10 USD $0.46288
≥100 USD $0.438944
≥500 USD $0.360712
Inventory: 9046
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6 Thin, TSOT-23-6
Number of Pins 6
Weight 36.003894mg

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series D-CAP2?, Eco-Mode?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.95mm
Base Part Number TPS562200
Function Step-Down
Number of Outputs 1
Output Voltage 7V
Output Type Adjustable
Max Output Current 2A
Operating Supply Voltage 17V
Input Voltage-Nom 12V
Min Supply Voltage 4.5V
Analog IC - Other Type SWITCHING REGULATOR
Operating Supply Current 230μA
Output Configuration Positive
Quiescent Current 230μA
Max Output Voltage 7V
Voltage - Output (Min/Fixed) 0.765V
Topology Buck
Frequency - Switching 650kHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Min Output Voltage 765mV
Voltage - Output (Max) 7V

Dimensions

Height 1.1mm
Length 2.9mm
Width 1.6mm
Thickness 870μm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
