TPS54550PWPG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 16-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description TPS54550 Tube Nickel/Palladium/Gold (Ni/Pd/Au) ACTIVE (Last Updated: 5days ago) DC to DC switching regulator 12V 4.4mm 6A 250kHz 500kHz
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.73975
≥1 USD $10.73975
≥10 USD $8.8122
≥100 USD $8.5367
≥500 USD $8.2612
≥1000 USD $7.9857
Inventory: 1198
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-PowerTSSOP (0.173, 4.40mm Width)
Number of Pins 16
Weight 62.709145mg

Technical

Operating Temperature -40°C~125°C TJ
Packaging Tube
Series SWIFT?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Base Part Number TPS54550
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 20V
Output Voltage 12V
Output Type Adjustable
Max Output Current 6A
Voltage - Input (Min) 4.5V
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Quiescent Current 9mA
Voltage - Output (Min/Fixed) 0.891V
Topology Buck
Control Mode VOLTAGE-MODE
Frequency - Switching 250kHz 500kHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Min Output Voltage 891mV
Voltage - Output (Max) 17.2V

Dimensions

Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
