TPS54360BDDAR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 8-PowerSOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description TPS54360 Tape & Reel (TR) Active Step-Down DC to DC switching regulator 12V 3.9mm 3.5A 100kHz~2.5MHz
PDF
/
Buying Options
Total Price: USD $1.01
Unit Price: USD $1.00998
≥1 USD $1.00998
≥10 USD $0.95281
≥100 USD $0.89888
≥500 USD $0.848
≥1000 USD $0.8
≥3000 USD $0.75472
Inventory: 6925
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mounting Type Surface Mount
Package / Case 8-PowerSOIC (0.154, 3.90mm Width)
Surface Mount YES

Technical

Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Series Eco-Mode?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
Terminal Position DUAL
Terminal Form GULL WING
Base Part Number TPS54360
JESD-30 Code R-PDSO-G8
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 60V
Output Type Adjustable
Voltage - Input (Min) 4.5V
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Current - Output 3.5A
Voltage - Output (Min/Fixed) 0.8V
Topology Buck, Split Rail
Control Mode CURRENT-MODE
Frequency - Switching 100kHz~2.5MHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Voltage - Output (Max) 58.8V

Dimensions

Length 4.9mm
Width 3.9mm

Compliance

RoHS Status ROHS3 Compliant
