TPS54233DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
SOIC Nickel/Palladium/Gold (Ni/Pd/Au) SWITCHING REGULATOR Lead Free DC to DC switching regulator 12V 3.9mm 2A 300kHz
PDF
/
Buying Options
Total Price: USD $1.79
Unit Price: USD $1.785968
≥1 USD $1.785968
≥10 USD $1.684878
≥100 USD $1.589499
≥500 USD $1.499533
≥1000 USD $1.414653
Inventory: 1519
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Number of Pins 8
Weight 72.603129mg
Technical
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Pin Count 8
Number of Outputs 1
Output Type Adjustable
Max Output Current 2A
Operating Supply Voltage 28V
Input Voltage-Nom 12V
Temperature Grade AUTOMOTIVE
Analog IC - Other Type SWITCHING REGULATOR
Current - Output 2A
Quiescent Current 110μA
Max Output Voltage 25V
Voltage - Output 25V
Min Input Voltage 3.5V
Control Mode CURRENT-MODE
Frequency - Switching 300kHz
Max Input Voltage 28V
Control Technique PULSE WIDTH MODULATION
Min Output Voltage 800mV
Switcher Configuration BUCK
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
