LMR36006CRNXR
RoHS
RoHS compliant
RoHS compliantPackage 12-VFQFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
CURRENT-MODE RoHS Compliant Adjustable Positive DC to DC switching regulator -40C~150C TJ 2.1MHz 600mA 2mm
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8085
≥1 USD $0.8085
Inventory: 1070
Minimum: 1
-
+
Technical Details
Technical
Current - Output 600mA
Voltage - Output (Min/Fixed) 1V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 2.1MHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier Yes
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 24V
Voltage - Input (Min) 4.2V
Output Type Adjustable
Output Voltage 3.3V
Voltage - Input (Max) 60V
Number of Outputs 1
Function Step-Down
Base Part Number LMR36006
Reach Compliance Code compliant
Terminal Form NO LEAD
Terminal Position QUAD
Additional Feature ALSO OPERATES WITH PFM MODE
Terminal Finish Matte Tin (Sn)
Number of Terminations 12
Moisture Sensitivity Level (MSL) 2
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Dimensions
Height Seated (Max) 0.9mm
Length 3mm
Width 2mm
Compliance
RoHS Status RoHS Compliant
Physical
Surface Mount YES
Package / Case 12-VFQFN
Mounting Type Surface Mount, Wettable Flank
Supply Chain
Factory Lead Time 6 Weeks
