LM2772SD
RoHS
/
Package 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
VOLTAGE-MODE Non-RoHS Compliant Fixed Positive DC to DC switching regulator -30C~85C TA 1.15MHz 150mA 3mm
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.90398
≥1 USD $0.90398
≥10 USD $0.852808
≥100 USD $0.804542
≥500 USD $0.758999
≥1000 USD $0.716034
Inventory: 1639
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-WFDFN Exposed Pad
Number of Pins 10
Technical
Operating Temperature -30°C~85°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Terminal Pitch 0.5mm
Base Part Number LM2772
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage 1.2V
Output Type Fixed
Voltage - Input (Min) 2.7V
Input Voltage-Nom 3.6V
Analog IC - Other Type SWITCHED CAPACITOR REGULATOR
Output Configuration Positive
Current - Output 150mA
Quiescent Current 50μA
Topology Charge Pump
Control Mode VOLTAGE-MODE
Frequency - Switching 1.15MHz
Control Technique PULSE FREQUENCY MODULATION
Synchronous Rectifier No
Min Output Voltage 1.2V
Switcher Configuration BUCK
Dimensions
Height Seated (Max) 0.8mm
Width 3mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
