LM2687LDX
RoHS
/
Package 8-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LM2687 Tape & Reel (TR) Tin/Lead (Sn/Pb) Obsolete DC to DC switching regulator 3.6V 3mm 10mA 110kHz
PDF
/
Buying Options
Total Price: USD $26.82
Unit Price: USD $26.8204
≥1 USD $26.8204
≥10 USD $22.00675
≥100 USD $21.31895
≥500 USD $20.63115
≥1000 USD $19.94335
Inventory: 1480
Minimum: 1
-
+
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Other Analog ICs
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) 235
Terminal Pitch 0.5mm
Base Part Number LM2687
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 5.5V
Output Voltage -1.5V
Output Type Adjustable
Voltage - Input (Min) 2.7V
Input Voltage-Nom 3.6V
Max Supply Voltage 5.5V
Min Supply Voltage 2.7V
Analog IC - Other Type SWITCHED CAPACITOR REGULATOR
Output Configuration Negative
Current - Output 10mA
Quiescent Current 500μA
Max Output Voltage -5.2V
Topology Charge Pump
Logic Function Inverting
Frequency - Switching 110kHz
Synchronous Rectifier No
Min Output Voltage -1.5V
Switcher Configuration DOUBLER INVERTER
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Dimensions
Width 3mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Number of Pins 8
Package / Case 8-WFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
