LM2673S-12
RoHS
/
Package TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LM2673 Tube Tin/Lead (Sn/Pb) NRND (Last Updated: 3days ago) DC to DC switching regulator 12V 8.89mm 3A 260kHz
PDF
/
Buying Options
Total Price: USD $4.07
Unit Price: USD $4.06885
≥1 USD $4.06885
≥10 USD $3.3383
≥100 USD $3.23475
≥500 USD $3.13025
≥1000 USD $3.02575
Inventory: 1446
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Thickness 4.44mm
Width 8.89mm
Length 10.1mm
Height 4.65mm
Technical
Nominal Output Voltage 12V
Min Output Voltage 12V
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Topology Buck
Max Output Voltage 12V
Quiescent Current 4.2mA
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Min Supply Voltage 8V
Max Supply Voltage 40V
Input Voltage-Nom 24V
Max Output Current 3A
Output Type Fixed
Output Voltage 12V
Voltage - Input (Max) 40V
Efficiency 94 %
Number of Outputs 1
Function Step-Down
Base Part Number LM2673
Frequency 260kHz
Current Rating 3A
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position SINGLE
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
JESD-609 Code e0
Series SIMPLE SWITCHER?
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 7
Package / Case TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 3 days ago)
