LM2662M
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LM2662 Tube Tin/Lead (Sn/Pb) NRND (Last Updated: 2days ago) DC to DC switching regulator 5V 3.91mm 200mA 735mW
PDF
/
Buying Options
Total Price: USD $1.46
Unit Price: USD $1.458961
≥1 USD $1.458961
Inventory: 612
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Switcher Configuration DOUBLER INVERTER
Min Output Voltage -5.5V
Synchronous Rectifier No
Supply Current-Max (Isup) 4mA
Frequency - Switching 10kHz 75kHz
Logic Function Inverting
Topology Charge Pump
Voltage - Output (Min/Fixed) -Vin 2Vin Vin/2
Max Output Voltage -1.5V
Output Power 735mW
Quiescent Current 1.3mA
Current - Output 200mA
Power Dissipation 735mW
Output Configuration Positive or Negative
Analog IC - Other Type SWITCHED CAPACITOR CONVERTER
Min Supply Voltage 1.5V
Max Supply Voltage 5.5V
Input Voltage-Nom 5V
Max Output Current 250mA
Output Type Fixed
Output Voltage -5.5V
Number of Outputs 1
Function Ratiometric
Base Part Number LM2662
Frequency 150kHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Analog ICs
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 2 days ago)
