LM2598SX-5.0
RoHS
/
Package TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
VOLTAGE-MODE Non-RoHS Compliant Fixed Positive Switching Regulator IC -40C~125C TJ 150kHz 1A 8.635mm
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.755
≥1 USD $2.755
≥10 USD $2.26005
≥100 USD $2.18975
≥500 USD $2.11945
≥1000 USD $2.0482
Inventory: 10068
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 8.635mm
Height Seated (Max) 4.8mm
Technical
Min Output Voltage 5V
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 150kHz
Control Mode VOLTAGE-MODE
Topology Buck
Voltage - Output (Min/Fixed) 5V
Quiescent Current 5mA
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 24V
Voltage - Input (Min) 4.5V
Operating Supply Voltage 40V
Max Output Current 1A
Output Type Fixed
Output Voltage 5V
Number of Outputs 1
Function Step-Down
Base Part Number LM2598
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 235
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
JESD-609 Code e0
Series SIMPLE SWITCHER?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 7
Package / Case TO-263-8, D2Pak (7 Leads + Tab), TO-263CA
Mounting Type Surface Mount
Mount Surface Mount
