LM2577MX-12
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LM2577 Tape & Reel (TR) Obsolete Step-Up Step-Up/Step-Down DC to DC switching regulator 5V 7.5mm 3A Switch 52kHz
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.36465
≥1 USD $5.36465
≥10 USD $4.40135
≥100 USD $4.26455
≥500 USD $4.1268
≥1000 USD $3.98905
Inventory: 1184
Minimum: 1
-
+
Technical Details
Technical
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 220
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LM2577
JESD-30 Code R-PDSO-G24
Function Step-Up, Step-Up/Step-Down
Number of Outputs 1
Voltage - Input (Max) 40V
Output Voltage 12V
Output Type Fixed
Voltage - Input (Min) 3.5V
Input Voltage-Nom 5V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive or Negative
Current - Output 3A Switch
Topology Boost, Flyback, Forward Converter
Control Mode CURRENT-MODE
Frequency - Switching 52kHz
Control Technique PULSE WIDTH MODULATION
Synchronous Rectifier No
Pbfree Code no
JESD-609 Code e0
Series SIMPLE SWITCHER?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
