LM2574HVMX-ADJ
RoHS
/
Package 14-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
VOLTAGE-MODE Non-RoHS Compliant Adjustable Positive DC to DC switching regulator -40C~125C TJ 52kHz 500mA 7.5mm
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.4903
≥1 USD $3.4903
≥10 USD $2.86425
≥100 USD $2.77495
≥500 USD $2.68565
≥1000 USD $2.5954
Inventory: 1505
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Length 9mm
Height Seated (Max) 2.65mm
Technical
Voltage - Output (Max) 37V
Min Output Voltage 1.23V
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 52kHz
Control Mode VOLTAGE-MODE
Topology Buck
Max Output Voltage 37V
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 12V
Voltage - Input (Min) 4V
Max Output Current 500mA
Output Type Adjustable
Output Voltage 57V
Voltage - Input (Max) 60V
Number of Outputs 1
Function Step-Down
Base Part Number LM2574
Peak Reflow Temperature (Cel) 220
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Series SIMPLE SWITCHER?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 14
Package / Case 14-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
