STBB1-APUR
RoHS
RoHS compliant
RoHS compliantPackage 10-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
STBB1 Tape & Reel (TR) Matte Tin (Sn) - annealed ACTIVE (Last Updated: 6months ago) DC to DC switching regulator 3.6V 3mm 1.6A Switch 1.5MHz
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
≥10 USD $2.33904
≥100 USD $2.206688
≥500 USD $1.88012
≥1000 USD $1.76535
≥3000 USD $1.544664
Inventory: 4453
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 1mm
Technical
Max Junction Temperature (Tj) 150°C
Switcher Configuration PUSH-PULL
Min Output Voltage 1.2V
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 1.5MHz
Control Mode CURRENT-MODE
Topology Buck-Boost
Max Output Voltage 5.5V
Current - Output 1.6A Switch
Output Configuration Positive
Analog IC - Other Type DUAL SWITCHING CONTROLLER
Min Supply Voltage 2V
Max Supply Voltage 5.5V
Input Voltage-Nom 3.6V
ESR (Equivalent Series Resistance) 1.1Ohm
Voltage - Input (Min) 2V
Max Output Current 1A
Output Type Adjustable
Output Voltage 5.5V
Efficiency 94 %
Number of Outputs 1
Function Step-Up/Step-Down
Base Part Number STBB1
Time@Peak Reflow Temperature-Max (s) 30
Depth 2.79mm
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TJ
Physical
Number of Pins 10
Package / Case 10-VFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 14 Weeks
