L6925D013TR
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
L6925 Tape & Reel (TR) Matte Tin (Sn) - annealed Obsolete DC to DC switching regulator 3.6V 3mm 800mA 600kHz
PDF
/
Buying Options
Total Price: USD $2.34
Unit Price: USD $2.3408
≥1 USD $2.3408
≥10 USD $2.1032
≥100 USD $1.984224
≥500 USD $1.690568
≥1000 USD $1.587379
≥3000 USD $1.388974
Inventory: 1243
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Technical
Synchronous Rectifier Yes
Frequency - Switching 600kHz
Control Mode CURRENT-MODE
Topology Buck
Voltage - Output (Min/Fixed) 0.6V
Quiescent Current 25μA
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.7V
Max Output Current 800mA
Output Type Adjustable
Output Voltage 5.5V
Voltage - Input (Max) 5.5V
Efficiency 95 %
Number of Outputs 1
Function Step-Down
Base Part Number L6925
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Switching Regulator or Controllers
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
