L4971D
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
L4971 Tube Nickel/Palladium/Gold (Ni/Pd/Au) ACTIVE (Last Updated: 7months ago) DC to DC switching regulator 440mV 7.6mm 1.5A 100kHz~300kHz
PDF
/
Buying Options
Total Price: USD $3.63
Unit Price: USD $3.6256
≥1 USD $3.6256
≥10 USD $3.25952
≥100 USD $3.081971
≥500 USD $2.67095
≥1000 USD $2.534013
≥3000 USD $2.273744
Inventory: 1036
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 7.6mm
Length 10.5mm
Height 2.35mm
Technical
Voltage - Output (Max) 50V
Min Output Voltage 3.3V
Dropout Voltage 440mV
Synchronous Rectifier No
Supply Current-Max (Isup) 6mA
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 100kHz~300kHz
Control Mode VOLTAGE-MODE
Topology Buck
Max Output Voltage 50V
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 24V
Voltage - Input (Min) 8V
Max Output Current 1.5A
Output Type Adjustable
Output Voltage 50V
Voltage - Input (Max) 55V
Efficiency 85 %
Number of Outputs 1
Function Step-Down
Base Part Number L4971
Time@Peak Reflow Temperature-Max (s) 30
Frequency 300GHz
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BCDMOS
Subcategory Switching Regulator or Controllers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 25 Weeks
