PQ1CG38M2RZH image
Favorite
PQ1CG38M2RZH image
Favorite
RoHS
/
Package TO-220-5 Formed Leads
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description RoHS Compliant Adjustable Positive or Negative Through Hole DC to DC switching regulator -20C~80C TA 300kHz 800mA -30V
PDF
/
Inventory: 6166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant

Technical

Voltage - Output (Max) 35V -30V
Synchronous Rectifier No
Frequency - Switching 300kHz
Topology Buck
Voltage - Output (Min/Fixed) ±1.26V
Current - Output 800mA
Output Configuration Positive or Negative
Voltage - Input (Min) 8V
Output Type Adjustable
Output Voltage -30V
Voltage - Input (Max) 35V
Number of Outputs 1
Function Step-Down
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2006
Packaging Tube
Operating Temperature -20°C~80°C TA

Physical

Supplier Device Package TO-220-5
Package / Case TO-220-5 Formed Leads
Mounting Type Through Hole
Mount Through Hole
