SC34063AP1G image
Favorite
SC34063AP1G image
Favorite
RoHS
RoHS RoHS compliant
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description Tube MATTE TIN Obsolete Step-Up Step-Down DC to DC switching regulator 5V 7.62mm 1.5A Switch 33kHz
PDF
/
Buying Options
Total Price: USD $3.89
Unit Price: USD $3.8874
≥1 USD $3.8874
≥10 USD $3.1901
≥100 USD $3.09035
≥500 USD $2.9906
≥1000 USD $2.89085
Inventory: 21008
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 7.62mm
Length 9.78mm
Height Seated (Max) 4.45mm

Technical

Voltage - Output (Max) 40V Switch
Switcher Configuration BUCK-BOOST
Synchronous Rectifier No
Frequency - Switching 33kHz
Topology Buck, Boost
Voltage - Output (Min/Fixed) 1.25V
Current - Output 1.5A Switch
Output Configuration Positive or Negative
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 5V
Voltage - Input (Min) 3V
Output Type Adjustable
Voltage - Input (Max) 40V
Number of Outputs 1
Function Step-Up, Step-Down
JESD-30 Code R-PDIP-T8
Terminal Pitch 2.54mm
Terminal Position DUAL
Terminal Finish MATTE TIN
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~70°C TA

Physical

Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
