FAN2106EMPX
RoHS
RoHS compliant
RoHS compliantPackage 25-WQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
FAN2106 Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au) ACTIVE NOT REC (Last Updated: 6days ago) DC to DC switching regulator 12V 5mm 6A 200kHz~600kHz
PDF
/
Buying Options
Total Price: USD $4.04
Unit Price: USD $4.04225
≥1 USD $4.04225
≥10 USD $3.31645
≥100 USD $3.2129
≥500 USD $3.10935
≥1000 USD $3.0058
Inventory: 1208
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5mm
Length 6mm
Height Seated (Max) 0.8mm
Technical
Voltage - Output (Max) 19.2V
Min Output Voltage 800mV
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 200kHz~600kHz
Control Mode CURRENT-MODE
Topology Buck
Voltage - Output (Min/Fixed) 0.8V
Max Output Voltage 19.2V
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 12V
Voltage - Input (Min) 3V
Operating Supply Voltage 24V
Max Output Current 6A
Output Type Adjustable
Output Voltage 19.2V
Efficiency 95 %
Number of Outputs 1
Function Step-Down
Base Part Number FAN2106
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology BICMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 25
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e4
Series TinyBuck?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 240mg
Number of Pins 25
Package / Case 25-WQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE, NOT REC (Last Updated: 6 days ago)
