MP1591DN-LF image
Favorite
MP1591DN-LF image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description Tube Matte Tin (Sn) Active Step-Down DC to DC switching regulator 12V 3.9mm 2A 330kHz
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.339182
≥1 USD $0.339182
≥10 USD $0.31998
≥100 USD $0.301874
≥500 USD $0.284785
≥1000 USD $0.268662
Inventory: 5137
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 3.9mm
Length 4.9mm

Technical

Min Output Voltage 1.23V
Synchronous Rectifier Yes
Frequency - Switching 330kHz
Control Mode CURRENT-MODE
Topology Buck
Max Output Voltage 21V
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 12V
Voltage - Input (Min) 6.5V
Operating Supply Voltage 32V
Max Output Current 2A
Output Type Adjustable
Output Voltage 21V
Voltage - Input (Max) 32V
Efficiency 95 %
Number of Outputs 1
Function Step-Down
JESD-30 Code R-PDSO-G8
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C TA

Physical

Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
