MIC4950YFL-TR
RoHS
RoHS compliant
RoHS compliantPackage 10-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
ROHS3Compliant Adjustable Positive Surface Mount DC to DC switching regulator -40C~125C TJ Up to 3.3MHz 5A 5.5V
PDF
/
Inventory: 8110
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Output (Max) 5.5V
Min Output Voltage 625mV
Synchronous Rectifier Yes
Max Input Voltage 5.5V
Frequency - Switching Up to 3.3MHz
Min Input Voltage 2.7V
Topology Buck
Voltage - Output (Min/Fixed) 0.625V
Max Output Voltage 5.5V
Current - Output 5A
Output Configuration Positive
Operating Supply Current 2mA
Min Supply Voltage 2.7V
Voltage - Input (Min) 2.7V
Output Type Adjustable
Voltage - Input (Max) 5.5V
Number of Outputs 1
Function Step-Down
Base Part Number MIC4950
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Hyper Speed Control?
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Supplier Device Package 10-DFN (3x4)
Number of Pins 10
Package / Case 10-VDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 23 Weeks
