MIC4684BM
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
Non-RoHS Compliant Adjustable Positive Surface Mount Switching Regulator IC -40C~85C TA 200kHz 2A 30V
PDF
/
Buying Options
Total Price: USD $11.06
Unit Price: USD $11.0599
≥1 USD $11.0599
≥10 USD $9.07535
≥100 USD $8.7913
≥500 USD $8.5082
≥1000 USD $8.22415
Inventory: 767
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Supplier Device Package 8-SOIC
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2005
Series SuperSwitcher?
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number MIC4684
Function Step-Down
Number of Outputs 1
Voltage - Input (Max) 30V
Output Type Adjustable
Voltage - Input (Min) 4V
Output Configuration Positive
Current - Output 2A
Voltage - Output (Min/Fixed) 1.235V
Topology Buck
Frequency - Switching 200kHz
Synchronous Rectifier No
Voltage - Output (Max) 28.2V
Compliance
RoHS Status Non-RoHS Compliant
