MIC33M656-SAYMP-TR

Microchip Technology
RoHS
RoHS RoHS compliant
Package 53-PowerBFQFN Module
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description ROHS3Compliant Programmable Positive QUAD DC to DC switching regulator -40C~125C TJ 1.6MHz 2.2MHz 6A 6mm
PDF
/
Buying Options
Total Price: USD $4.7
Unit Price: USD $4.6992
≥1 USD $4.6992
≥10 USD $3.916
≥100 USD $3.795
Inventory: 297
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 6mm
Height Seated (Max) 3.05mm

Technical

Voltage - Output (Max) 3.84V
Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 1.6MHz 2.2MHz
Topology Buck
Voltage - Output (Min/Fixed) 0.6V
Current - Output 6A
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 5V
Voltage - Input (Min) 2.4V
Output Type Programmable
Output Voltage 1V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Function Step-Down
JESD-30 Code R-PQMA-N53
Terminal Pitch 0.5mm
Terminal Form NO LEAD
Terminal Position QUAD
Technology HYBRID
Number of Terminations 53
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series HyperLight Load?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ

Physical

Surface Mount YES
Package / Case 53-PowerBFQFN Module
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
