MIC23159YML-T5
RoHS
RoHS compliant
RoHS compliantPackage 20-VFQFN Exposed Pad, 20-MLF?
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
MIC23159 Cut Tape (CT) Active Step-Down DC to DC switching regulator 5.5V 3mm 2A 3MHz
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.04113
≥1 USD $1.04113
≥10 USD $0.880956
≥30 USD $0.792992
≥100 USD $0.693211
≥500 USD $0.648573
≥1000 USD $0.628879
Inventory: 1161
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-VFQFN Exposed Pad, 20-MLF?
Number of Pins 20
Supplier Device Package 20-MLF? (3x4)
Technical
Operating Temperature -40°C~125°C TJ
Packaging Cut Tape (CT)
Published 2016
Series HyperLight Load?
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Base Part Number MIC23159
Function Step-Down
Number of Outputs 2
Efficiency 94 %
Voltage - Input (Max) 5.5V
Output Voltage 3.3V
Output Type Adjustable
Max Output Current 2A
Voltage - Input (Min) 2.7V
Output Configuration Positive
Current - Output 2A
Max Output Voltage 3.3V
Voltage - Output (Min/Fixed) 1V
Topology Buck
Min Input Voltage 2.7V
Frequency - Switching 3MHz
Max Input Voltage 5.5V
Synchronous Rectifier Yes
Min Output Voltage 1V
Voltage - Output (Max) 3.3V
Dimensions
Height 800μm
Length 4mm
Width 3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
