MIC2142BD5 TR

Microchip Technology
RoHS
/
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description Non-RoHS Compliant Adjustable Positive Surface Mount DC to DC switching regulator -40C~85C TA 330kHz 200mA 16V
PDF
/
Inventory: 969
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case SC-74A, SOT-753

Technical

Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2007
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Base Part Number MIC2142
Function Step-Up, Step-Up/Step-Down
Number of Outputs 1
Voltage - Input (Max) 16V
Output Type Adjustable
Voltage - Input (Min) 2.2V
Output Configuration Positive
Current - Output 200mA
Topology Boost, Flyback, SEPIC
Frequency - Switching 330kHz
Synchronous Rectifier No
Voltage - Output (Max) 22V

Compliance

RoHS Status Non-RoHS Compliant
