MAX16993ATJF+T
RoHS
RoHS compliant
RoHS compliantPackage 32-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
Tape & Reel (TR) Active Step-Down 2015 DC to DC switching regulator 3.95V 0.5mm 3A 2.1MHz
PDF
/
Buying Options
Total Price: USD $9.36
Unit Price: USD $9.359964
≥1 USD $9.359964
≥10 USD $8.830156
≥100 USD $8.330335
≥500 USD $7.858811
≥1000 USD $7.413965
Inventory: 1245
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-WFQFN Exposed Pad
Number of Pins 32
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Published 2015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
ECCN Code EAR99
Subcategory Switching Regulator or Controllers
Terminal Position QUAD
Terminal Pitch 0.5mm
Function Step-Down
Number of Outputs 3
Output Voltage 3.95V
Output Type Adjustable (Programmable)
Max Output Current 3A
Operating Supply Voltage 36V
Voltage - Input (Min) 3.5V
Output Configuration Positive
Max Output Voltage 3.95V
Voltage - Output (Min/Fixed) 0.8V 3.3V 5V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 2.1MHz
Synchronous Rectifier Yes
Min Output Voltage 5V
Voltage - Output (Max) 3.95V
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
