MAX16903SATB50/V+T
RoHS
RoHS compliant
RoHS compliantPackage 10-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
MAX16903 Tape & Reel (TR) Active Step-Down DC to DC switching regulator 28V 0.5mm 1A 2.1MHz
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 17
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Synchronous Rectifier Yes
Frequency - Switching 2.1MHz
Control Mode CURRENT-MODE
Topology Buck
Output Configuration Positive
Voltage - Input (Min) 3.5V
Operating Supply Voltage 28V
Max Output Current 1A
Output Type Fixed
Output Voltage 5V
Voltage - Input (Max) 28V
Number of Outputs 1
Function Step-Down
Base Part Number MAX16903
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 10
Package / Case 10-WFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
