LTC3646IMSE#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-TFSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LTC3646 Tube Matte Tin (Sn) Active DC to DC switching regulator 12V 3mm 1A 200kHz~3MHz
PDF
/
Buying Options
Total Price: USD $7.97
Unit Price: USD $7.9728
≥1 USD $7.9728
≥10 USD $7.20456
≥100 USD $6.868998
≥500 USD $5.96442
≥1000 USD $5.696319
≥3000 USD $5.193698
Inventory: 693
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-TFSOP (0.118, 3.00mm Width) Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2012
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Switching Regulator or Controllers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LTC3646
Function Step-Down
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Input (Max) 40V
Output Voltage 5V
Output Type Adjustable
Voltage - Input (Min) 4V
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING REGULATOR
Output Configuration Positive
Current - Output 1A
Voltage - Output (Min/Fixed) 2V
Topology Buck
Control Mode CURRENT-MODE
Frequency - Switching 200kHz~3MHz
Synchronous Rectifier Yes
Voltage - Output (Max) 30V
Dimensions
Length 4.039mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
