LTC3633IFE#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LTC3633 ALSO OPERATES AS LDO REGULATOR Tape & Reel (TR) Matte Tin (Sn) DC to DC switching regulator 12V 4.4mm 3A 500kHz~4MHz
PDF
/
Buying Options
Total Price: USD $16.11
Unit Price: USD $16.10915
≥1 USD $16.10915
≥10 USD $13.2183
≥100 USD $12.80505
≥500 USD $12.3918
≥1000 USD $11.97855
Inventory: 486
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Length 9.7mm
Technical
Synchronous Rectifier Yes
Frequency - Switching 500kHz~4MHz
Control Mode CURRENT-MODE
Topology Buck
Voltage - Output (Min/Fixed) 0.6V
Current - Output 3A
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Number of Channels 1
Input Voltage-Nom 12V
Voltage - Input (Min) 3.6V
Output Type Adjustable
Output Voltage 14.7V
Voltage - Input (Max) 15V
Efficiency 95 %
Qualification Status Not Qualified
Number of Outputs 2
Function Step-Down
Base Part Number LTC3633
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Switching Regulator or Controllers
Additional Feature ALSO OPERATES AS LDO REGULATOR
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-TSSOP (0.173, 4.40mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 8 Weeks
