LTC3535EDD#PBF
RoHS
RoHS compliant
RoHS compliantPackage 12-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LTC3535 Tube Matte Tin (Sn) PRODUCTION (Last Updated: 3weeks ago) DC to DC switching regulator 1.2V 3mm 550mA Switch 1MHz
PDF
/
Buying Options
Total Price: USD $7.49
Unit Price: USD $7.4888
≥1 USD $7.4888
≥10 USD $6.76456
≥100 USD $6.450048
≥500 USD $5.600505
≥1000 USD $5.348798
≥3000 USD $4.876846
Inventory: 165
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Current - Output 2 550mA
Min Output Voltage 1.5V
Synchronous Rectifier Yes
Current - Output 1 550mA
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 1MHz
Control Mode CURRENT-MODE
Topology Boost
Voltage - Output (Min/Fixed) 1.5V
Voltage - Output 2 5.25V
Max Output Voltage 5.25V
Current - Output 550mA Switch
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Number of Channels 1
Input Voltage-Nom 1.2V
Voltage - Input (Min) 0.5V
Voltage - Output 1 5.25V
Output Type Adjustable
Output Voltage 5.25V
Voltage - Input (Max) 5V
Efficiency 94 %
Qualification Status Not Qualified
Number of Outputs 2
Function Step-Up
Base Part Number LTC3535
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.45mm
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology CMOS
Subcategory Switching Regulator or Controllers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 12
Surface Mount YES
Package / Case 12-WFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
Alternative Model
