LTC3410BESC6#TRMPBF image
Favorite
LTC3410BESC6#TRMPBF image
Favorite
RoHS
RoHS RoHS compliant
Package 6-VSSOP, SC-88, SOT-363
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description LTC3410 Tape & Reel (TR) Matte Tin (Sn) PRODUCTION (Last Updated: 3weeks ago) DC to DC switching regulator 3.6V 2mm 300mA 2.25MHz
PDF
/
Buying Options
Total Price: USD $4.38
Unit Price: USD $4.3824
≥1 USD $4.3824
≥10 USD $3.93448
≥100 USD $3.719584
≥500 USD $3.223704
≥1000 USD $3.058352
Inventory: 590
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length 2mm

Technical

Synchronous Rectifier Yes
Control Technique PULSE WIDTH MODULATION
Frequency - Switching 2.25MHz
Control Mode CURRENT-MODE
Topology Buck
Voltage - Output (Min/Fixed) 0.8V
Current - Output 300mA
Output Configuration Positive
Analog IC - Other Type SWITCHING REGULATOR
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.5V
Output Type Adjustable
Output Voltage 5.5V
Efficiency 96 %
Qualification Status Not Qualified
Number of Outputs 1
Function Step-Down
Base Part Number LTC3410
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Number of Pins 6
Surface Mount YES
Package / Case 6-VSSOP, SC-88, SOT-363
Mounting Type Surface Mount

Supply Chain

Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
