LTC3240EDC-3.3#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 6-WFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description
LTC3240 Tape & Reel (TR) Matte Tin (Sn) Active DC to DC switching regulator 2.4V 2mm 150mA 1.2MHz
PDF
/
Buying Options
Total Price: USD $5.06
Unit Price: USD $5.06
≥1 USD $5.06
≥10 USD $4.54784
≥100 USD $4.29968
≥500 USD $3.726272
≥1000 USD $3.535206
≥3000 USD $3.172118
Inventory: 500
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 2mm
Length 2mm
Height Seated (Max) 0.8mm
Technical
Switcher Configuration DOUBLER INVERTER
Synchronous Rectifier No
Frequency - Switching 1.2MHz
Topology Charge Pump
Voltage - Output (Min/Fixed) 3.3V
Current - Output 150mA
Output Configuration Positive
Analog IC - Other Type SWITCHED CAPACITOR REGULATOR
Input Voltage-Nom 2.4V
Voltage - Input (Min) 1.8V
Output Type Fixed
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Number of Outputs 1
Function Step-Up/Step-Down
JESD-30 Code S-PDSO-N6
Base Part Number LTC3240
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Subcategory Other Analog ICs
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 6-WFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
